Home ProductsRidge Cap Roll Forming Machine

Automatic Roof Ridge Cap Tile Cold Roll Forming Machine / Glazed Aluminum Metal Rib Tile Forming Machine

Certification
Good quality Automatic Roll Forming Machines for sales
Good quality Automatic Roll Forming Machines for sales
I'm Online Chat Now

Automatic Roof Ridge Cap Tile Cold Roll Forming Machine / Glazed Aluminum Metal Rib Tile Forming Machine

China Automatic Roof Ridge Cap Tile Cold Roll Forming Machine / Glazed Aluminum Metal Rib Tile Forming Machine supplier
Automatic Roof Ridge Cap Tile Cold Roll Forming Machine / Glazed Aluminum Metal Rib Tile Forming Machine supplier Automatic Roof Ridge Cap Tile Cold Roll Forming Machine / Glazed Aluminum Metal Rib Tile Forming Machine supplier

Large Image :  Automatic Roof Ridge Cap Tile Cold Roll Forming Machine / Glazed Aluminum Metal Rib Tile Forming Machine

Product Details:

Place of Origin: Botou,Hebei Province
Brand Name: XINGHE
Certification: BV,SGS, CE,ISO9001
Model Number: XH312

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Price: Negotiation
Packaging Details: Naked and fixed into container
Delivery Time: 30 Working days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 30 SETS / MONTH
Contact Now
Detailed Product Description
Condition: New Type: Tile Forming Machine
Tile Type: Colored Steel / PPGI / Galvanized Steel Coil Power: 4.0+4.0kw
Voltage: 380V 60HZ Or At Your Requirement Dimension: 6500*1000*1200mm
Machine Weight: 3.0Tons Warrenty: 12 Months Warrenty And Long-life After-sale Service
After-sales Service: Engineers Available To Service Machinery Middle Plate Thickness: 14mm
Control System:: PLC(imported Brand) Roller Material:: 45#steel Chrome Plated
Shaft Material:: 5mm Chrome Coated PLC Automatic Zinc Roofing Roll Forming Machine/Corrugated Roof Sheet Making Machine/ Roof Panel For: 75mm
Cutting Blade Material: Cr 12 High Grade Steel

  Ridge cap roll forming machine for steel is the special equipment for continuous rolling and cold-forming on steel sheet. It adopts coiling steel sheet as the raw material, decoiling the coil, continuous rolling and cold-forming, automatically cut to the size and output the finished panel. The equipment adopts PLC control, AC frequency and adjusting the speed technology, and it realizes the continuous automatically production, therefore, it is really a new type of energy-saving and high-effective producing equipment for steel structure.

COMPONENT FOR CE Standard Profile Metal Steel Ridge Cap Roll Forming Machine With Low Price
Name
Units
Quantity
Decoiler
Set
1
Main machine
Pre-cutting device
Set
1
Feeding device
Set
1
Roll forming system
Set
1
Punching Die and Post-cutting
Set
1
Hydraulic system
Set
1
Electric control system
Set
1
Supporter/Automatic Stacker
Set
1

Automatic Roof Ridge Cap Tile Cold Roll Forming Machine / Glazed Aluminum Metal Rib Tile Forming Machine

Automatic Roof Ridge Cap Tile Cold Roll Forming Machine / Glazed Aluminum Metal Rib Tile Forming Machine
