Product Details:
Payment & Shipping Terms:
|
| Condition: | New | Type: | Tile Forming Machine |
|---|---|---|---|
| Production: | 0-15m/min | Power: | 4.0+4.0kw |
| Voltage: | 380V 60HZ Or At Your Requirement | After-sale: | Engineers Available To Service |
| High Light: | storage rack roll forming machine,cnc roll forming machine |
||
What is the type?
Equipment components:
Man-made uncoiler, Roll forming machine, computer control system, hydraulic control system, cutting
Main parameter
| 1.Technical parameter | ||||
| Roll Forming Machine | Specification | |||
Raw Material |
Type | Pre-painted steel coil & galvanized coils, Aluminum coil | ||
| Thickness | 0.3-0.6mm | |||
| Width | 333mm | |||
| Roller material | 45# steel , coated with Chrome | |||
| Roller | 16 rows | |||
| Shaft for rollers | Solid shaft with 70mm,processed with cylindrical grinder | |||
| Forming capacity | About 8-10m/min | |||
| Roller drive | Decelerating motor + Chain drive | |||
| Cutting mode | Hydraulic cutting | |||
| Cutter material | Cr12 mould steel | |||
| Control mode | PLC control system | |||
| Operating mode | Button + Touch screen | |||
| Main motor power(kw) | 3KW | |||
| Hydraulic power(kw) | 3 KW | |||
| Voltage | 380V 50Hz 3phases(can be design as your needs) | |||
| 2. Components of Machine | ||||
| Decoiler (manual decoiler and hydraulic decoiler for option) | 1set | |||
| Feeding & guiding device | 1set | |||
| Main roll forming machine | 1set | |||
| Hydraulic cutting system | 1set | |||
| Controlling system | 1set | |||
| Run out table (auto. Stacker for option) | 1set | |||
Our Services
Pre-sale Service
1. Send you invitation letter, If you wanna visit our factory and check the machines.
2. Good Quality Manufacturer competitive price Quick Response Reliable Service for you.
Selling Service
1. Short delivery time after deposit 30-40 days.
2. Email you the production schedule and make prompt delivery for you.
3. We will count the cheapest shipping cost and fastest forwarder for you and send documents promptly.
4. Always be here for your service 12 hours per day.
After-sale Service
1. We welcome all feedback about our products and prices and services from our customers.
2. Any questions, please contact with us freely by E-mail or Telephone.0086-13754536227 Kim Lee
