Corrugated Aluminum Steel Stud Roll Forming Machine With 17 - 44 Rows Rollers

China Corrugated Aluminum Steel Stud Roll Forming Machine With 17 - 44 Rows Rollers supplier
Corrugated Aluminum Steel Stud Roll Forming Machine With 17 - 44 Rows Rollers supplier Corrugated Aluminum Steel Stud Roll Forming Machine With 17 - 44 Rows Rollers supplier

Large Image :  Corrugated Aluminum Steel Stud Roll Forming Machine With 17 - 44 Rows Rollers

Product Details:

Place of Origin: Botou,Hebei Province
Certification: BV,SGS, CE,ISO9001

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Price: Negotiation
Packaging Details: Naked and fixed into container
Delivery Time: 20 Working days
Payment Terms: L/C, T/T
Supply Ability: 30 SETS / MONTH
Detailed Product Description
Condition: New Type: Tile Forming Machine
Tile Type: Colored Steel / PPGI Coil / Glavanized Sheet Coil Voltage: 380V 60HZ Or At Your Requirement
After-sale: Engineers Available To Service Sheet Thickness: 0.3~0.8mm
High Light:

sandwich panel production line

,

continuous sandwich panel line

Full Automatic EPS And Rock Wool Sandwich Roofing Production Line,EPS Sandwich Panel Machine



Working drawing
Automatic precast EPS concrete sandwich wall panel making machine/ production line



Sandwich roof machine details

No. Main parameter of Sandwich panel forming machine line
1 Suitable to process Color steel plate
2 Width of the plate 1000&1200mm
3 Rollers 17-44rows
4 Dimensions 20.0*2.25*2.5m
5 Power 30kw
6 Thickness of the plate 0.3-0.8mm
7 Productivity 2-6m/min
8 Diameter of the roller Φ90mm
9 Weight About 15 T
10 Voltage 380V 50Hz 3phases
11 Material of the cutting plate Cr12
12 Processing precision Within 1.00mm
13 Control system

PLC control





Sandwich panel machine line technical parameters



Sandwich panel standards

Length Min cut length: 3 m
Max stacker length: 15 m



Raw material standards

Coil thickness

0.4~0.6mm (the coil surface should be flat, no arch and the others

surface trouble.)

Material coil yield strength 235MPa
Material coil max width see detailed profile drawings.
Material coil max weight 5 T
Material coil inner diameter Φ508,Φ610 mm



EPS core material

density ≥18Kg/m3
straight rate ≤1mm/m
arch degree ≤3mm/m
panel surface

shoule be flat

no flat degree is ≤1.5mm/m,

sandwich panel length longer than 5 meters



Main parameters

No. main parameter of roll forming machine
1 suitable material Color Steel plate, galvanized sheet

2



Width of the plate 1200mm
effective surface 950/960/970/980mm
3 Rows of rollers 14 rows
4 Size 7.5*1.3*1.2m
5 Total power 4kw
6 Thickness of raw material 0.3-0.8mm
7 Productivity 8-10m/min
8 diameter of shaft 80mm
9 Weight About 4T
10 Voltage 380V 50Hz 3phases



Payment term and condition

1 Payment Term 30% T/T in advance, 70% T/T before shipment
2 Delivery Time Within 60 Working Days after receipt of the down payment
3 Warranty 1 year and life-long maintenance
4 Installation and commissioning

Our engineer will go to make installation there, Buyer pay

our engineer 100 USD /day, an



 Machine shows

Corrugated Aluminum Steel Stud Roll Forming Machine With 17 - 44 Rows Rollers

Corrugated Aluminum Steel Stud Roll Forming Machine With 17 - 44 Rows Rollers
